● Khoom Piav Qhia
● Kev ua tau zoo heev vim yog ob chav CPU ntse tswj.
● SES SESTABTIONS Cov khoom siv uas xav tau hom, lub zog -} kev txuag hom thiab roj teeb.
● Tswj cov kiv cua ntse uas muaj kev nyab xeeb dua thiab txhim khu kev qha.
● Cov Sine Wave Vis Strine Ac Tso Tawm, uas muaj peev xwm hloov kho rau ntau hom kev thauj khoom.
● LCD zaub cov khoom siv tsis nyob hauv lub sijhawm tiag tiag, uas qhia koj lub xeev khiav.
● Txhua yam kev tiv thaiv thiab lub tswb ntawm cov zis tshaj thiab Circuit Court.
Inser Cov neeg txawj ntse saib lub cuab yeej cuab tam yog ntawm RS485 kev sib txuas lus interface tsim qauv.
Kev Tiv Thaiv Theem Poob, Tso Tawm Ntau Tshaj, Kev Tiv Thaiv Luv Luv, Ntau Yam Kev Tiv Thaiv thiab Lus Ceeb Toom
| Tsis muaj | ib feem | rooj mov |
| ① | Xov xwm xov xwm | Lub Nroog Lub Zog Tawm Tsam, Roj Teeb Cov Lus Qhia, Inverter Tso Tawm, Lub Ntiaj Teb Hlau (Seedetail los ntawm Daim Duab1 thiab Daim Duab) |
| ② | Hloov ntawm lub roj teeb nkag | Tswj cov roj teeb sib txuas |
| ③ | Hloov ntawm inverter tsim tawm | Kev tswj ntawm cov zis load |
| ④ | Hloov ntawm Lub Nroog Lub Zog Hluav Taws Xob | Tswj Lub Nroog Fais Txuas Txuas |
| ⑤ | LCD zaub | Muab cov ntsuas ntawm inverter. |
| ⑥ | qhib / kaw khawm | Thaum lub kaw hluav taws xob tawm yog cov roj teeb ua ntej, thaum hloov mus rau yog cov phiaj xwm kev ua ntej (lossis cov khoom sib luag |
| ⑦ | lub tshuab cua | Txoj kev cua hlob txias yog sab hauv inverter, ceevfaj tsis txhob muaj cov khoom los jam. |
| ⑧ | 485 Kev Sib Txuas Lus | Kev sib txuas lus interface (xaiv tau) |
● Cov ntaub ntawv txheej txheem
|
Tus qauv |
10kw |
15kw |
20Kw |
25Kw |
30kw |
40kw |
|
|
Kev Muaj Peev Xwm |
10kw |
15kw |
20Kw |
25Kw |
30kw |
40kw |
|
|
Ua haujlwm hom thiab txoj ntsiab cai |
DSP Precision tswj thev naus laus zis thiab ua ke tsim -} hauv microprocessor pwg (mem tes dav kev hloov kho) tso zis lub zog yog cais tawm kiag li |
||||||
|
Ac tswv yim |
caij |
3Phases + n + g |
|||||
|
fai fab hov ntau |
AC220V / AC380V ± 20% |
||||||
|
hov ntau |
50Hz / 60HZ ± 5% |
||||||
|
Dc txoj hau kev |
DC voltage |
96VDC (10kW / 15kW) DC192V / DC220V / DC240V / DC380V【Koj tuaj yeem xaiv 16-32 12 v roj teeb】 |
|||||
|
Ntab roj teeb |
Ib ntu teeb roj teeb13.6v × Roj Teeb No.【xws li 13.6v × 16pcs＝217.6V】 |
||||||
|
Txiav - tawm ntawm voltage |
Ib feem teeb roj teeb10.8v × Roj Teeb No.【xws li 10.8v × 16pcs＝172.8V】 |
||||||
|
Ac tawm |
caij |
3Phases + n + g |
|||||
|
fai fab hov ntau |
AC220V / AC380V / 400V / 415V / 415V (Stocky Stock) |
||||||
|
hov ntau |
50Hz / 60Hz ± 5% (Lub nroog fais fab) 50Hz ± 0.01%(roj teeb muaj hwj chim) |
||||||
|
ua tau zoo |
Ntau dua los yog sib npaug rau 95%(Load tshuab00%%) |
||||||
|
Tso Tawm WaveFormform |
Ntshiab sine yoj |
||||||
|
TAG NRHO HARONED DEDORO |
Linear load＜3% nonlinear load＜5% |
||||||
|
Dynamic load voltage |
＜±5%(los ntawm 0 mus rau 100% saltus) |
||||||
|
Hloov sijhawm |
＜10s |
||||||
|
Hloov lub sijhawm ntawm roj teeb thiab lub nroog fais fab |
3S-5S |
||||||
|
Unbalanced voltage |
＜±3% ＜±1%(Balanced Load Voltage) |
||||||
|
Ntau dhau load muaj peev xwm |
120% 20s tiv thaiv, ntau dua 150%,100ms |
||||||
|
Qhov Txheej Txheem Index |
Ua haujlwm efficiency |
100% thauj khoom ntau dua los yog sib npaug rau 95% |
|||||
|
Kev khiav hauj lwm kub |
-20tiv kis-40tiv kis |
||||||
|
Tus txheeb ze cov av noo |
0-90% tsis muaj hws |
||||||
|
suab nrov |
40-50db |
||||||
|
lub tsev |
Qhov loj me d × w × h (hli) |
580*750*920 |
|||||
|
Luj kg) |
180 |
200 |
220 |
250 |
300 |
400 |
|
Yog tias koj xav paub ntau ntxiv txog hnub ci zog, thov nyem qhov no.
● Vim li cas thiaj xaiv Br Hnub Ci
1.Peb yuav muab cov lus qhia ntxaws ntxaws thiab cov ntaub ntawv nkag mus. Peb yuav npaj cov kws tshaj lij kev ua haujlwm los coj kev teeb tsa kom ntseeg tau tias koj qhov project tuaj yeem ntsia tau tiav. Yog tias muaj teeb meem nrog cov khoom lag luam thaum lub sijhawm lav, vim peb paub tias tsuas yog ib tus phooj ywg sib koom tes ua ke tau txais kev sib koom tes zoo dua.
 |
 |
 |
 |
 |
 |
2. Txog Br Hnub Ci
Peb tau ua tiav txoj kev txhim kho peb txoj kev teeb pom kev zoo, thiab cov roj teeb txawv teb chaws, cov hnub ci tshwj xeeb hauv tebchaws Asia, North & Ko Teb America, Africa, thiab lwm yam.
Peb tau txais txiaj ntsig dua li lwm tus neeg muag khoom:
a) muaj pov thawj los ntawm CE, RoHS, IEC, TUV, FACC, ISO9001: 2000, ccit, pvoc, thiab lwm yam, thiab lwm yam.
b) Cov kev daws teeb meem thiab cov neeg ua haujlwm tsim khoom.
c) Txhim khu kev qha zoo, tus nqi sib tw, xa khoom sai, cov lus teb sai thiab kev pabcuam zoo.
D) Kom ua kom peb cov kev ua lag luam hnub ci muaj zog rau peb cov neeg siv khoom, peb tab tom sim ua qhov zoo tshaj plaws ntawm koj qhov kev thov, kom ua tus nqi zoo tshaj plaws rau koj.
e) Kev sib txig kev teeb tsa rau cov xaj loj.
